- Minimizes the effects of wire/cable characteristics, such as shape, diameter, and unevenness, on
- Minimizes error arising from slipping during measurement.
- Minimizes wear on outer measuring wheel surface over time.
- Minimizes curving of wire/cable during measurement.
- Even a light load from five wire-stabilizing upper rollers will stabilize wire/cable.
- Wire-stabilizing upper rollers made of shock-absorbing polyurethane which absorbs slight vibrations from the wire/cable into the rollers.
- accuracy : better than +0.05% (standard test wire used)
(Please note that margin of error is always positive i.e.1000-1000.5 ft. for 1000 ft. measured.)
- repeatability : better than 0.02% (standard test wire used)
- wire/cable diameter range : 5mm - 50mm(0.197 - 1.969 in.)
- line speed : up to 200m(app.656 ft.)/min.
- weight : body 38kg(app.84 lbs.)
crossed parallel guide rollers(R and L) 20kg(app.44 lbs.)
